Diagonals for Common Module Sizes
Table of Diagonal Measurements (D1, D2) for Common Module
Sizes
(Dimensions in inches to nearest 32nd of an inch)
|
Length |
| Width |
24 in. |
48 in. |
60 in. |
72 in. |
84 in. |
96 in. |
| 12 in. |
26+27/32 |
49+15/32 |
61+3/16 |
73 in. |
84+27/32 |
96+3/4 |
| 16 in. |
28+27/32 |
50+19/32 |
62+3/32 |
73+3/4 |
85+1/2 |
97+5/16 |
| 18 in. |
30 in. |
51+1/4 |
62+21/32 |
74+7/32 |
85+29/32 |
97+11/16 |
| 20 in. |
31+1/4 |
52 in. |
63+1/4 |
74+23/32 |
86+11/32 |
98+1/16 |
| 24 in. |
33+15/16 |
53+21/32 |
64+5/8 |
75+29/32 |
87+3/8 |
98+31/32 |
| 29 in. |
37+21/32 |
56+3/32 |
66+21/32 |
77+5/8 |
88+7/8 |
100+9/32 |
| 30 in. |
38+13/32 |
56+19/32 |
67+3/32 |
78 in. |
89+3/16 |
100+19/32 |
| 36 in. |
43+9/32 |
60 in. |
69+31/32 |
80+1/2 |
91+3/8 |
102+17/32 |
